$166,900

Cámara de red tipo torreta fija Wi-Fi para interiores de 2 MP

  • Compatible con Wi-Fi 6
  • Micrófono y altavoz integrados, compatible con audio bidireccional
  • Buen rendimiento nocturno con hasta 20 m de infrarrojos y 15 m de luz blanca
  • WDR digital, HLC, BLC, DNR 3D
  • Imágenes de alta calidad con resolución de 2 MP



Categorías: , ,






Descripción
Cámara
Sensor de imagen1/3″ Progressive Scan CMOS
Max. Resolución1920 × 1080
Iluminación mínimaColor: 0.03 Lux @ (F2.2, AGC ON), B/W: 0.015Lux @(F2.2, AGC ON), 0 Lux with IR
Lente
Longitud focal2.8 mm;4 mm
FOVHorizontal field of view: 96.5°, vertical field of view: 52°, diagonal field of view: 115.5°;Horizontal field of view: 76.8°, vertical field of view: 42.5°, diagonal field of view: 89.7°
AperturaF2.2
Iluminador
Tipo de luz suplementariaIR,White Light
Rango de luz suplementariaWhite light distance: up to 15 m,IR distance: up to 20 m
IR Wavelength850 nm
PTZ
Rango de movimiento (pan)0° to 350°
Rango de movimiento (tilt)0° to 75°
Velocidad de movimiento horizontal (pan)Up to 20°/s
Velocidad de vertical (tilt)Up to 10°/s
Vídeo
Main stream50 Hz：25 fps（1920 × 1080，1280 × 720）
60 Hz：30 fps（1920 × 1080，1280 × 720）
Sub-stream50 Hz：25 fps（768 x 432）
60 Hz：30 fps（768 x 432）
Compresión de vídeoH.265, H.264, MJPEG
Vídeo bitrate32 Kbps to 8 Mbps
Tipo H.264Baseline Profile/Main Profile/High Profile
Tipo H.265Main Profile
Audio
Compresión de audioG.711ulaw/AAC-LC
Velocidad de bits de audioAAC-LC: 16 Kbps, 32 Kbps, 64 Kbps; G.711ulaw: 64 Kbps
Frecuencia de muestreo de audio8 kHz/16 kHz
Filtro de ruido ambientalYes
Red
ProtocolosIPv4/IPv6, HTTP, QoS, SMTP, NTP, RTSP, RTP, RTCP, TCP/IP, UDP, DHCP, Bonjour
APIOpen Network Video Interface (Version 18.12, Profile S, Profile G, Profile T), ISAPI, SDK, Hik-Connect
Usuario/operadorUp to 32 users. 3 user levels: administrator, operator, and user
SeguridadPassword protection,complicated password,watermark,basic and digest authentication for HTTP/HTTPS,WSSE and digest authentication for Open Network Video Interface, RTP/RTSP over HTTPS,security audit log,host authentication (MAC address)

Wired network: Hik-Connect, iVMS-4200

Wi-Fi: iVMS-4200

*Wi-Fi connection with Hik-Connect directly is not possible
Wireless (Wi-Fi)
Protocolos de Wi-FiIEEE802.11b,IEEE802.11g,IEEE802.11n,IEEE802.11ax
Rango de frecuencia2.4 GHz to 2.4835 GHz
Canal de ancho de banda20/40 MHz
Modulación802.11b: DBPSK, DQPSK, CCK,
802.11g: BPSK, QPSK, 16QAM, 64QAM,
802.11n: BPSK, QPSK, 16QAM, 64QAM,
802.11ax: BPSK, QPSK, 16QAM, 64QAM, 256QAM
Ratio de transferencia11b: up to 11 Mbps,11g: up to 54 Mbps,11n: up to 150 Mbps,11ax: up to 114 Mbps
Imagen
Configuración de imagenSaturation, brightness, contrast, and sharpness adjustable by client software or web browser
Wide Dynamic Range (WDR)Digital WDR
Mejora de la imagenBLC, HLC, 3D DNR
Máscara de privacidad4 programmable polygon privacy masks
Interfaz
Ethernet Interface1 RJ45 10M/100M self-adaptive Ethernet port
Micrófono incorporado1 built-in microphone
Almacenamiento a bordoBuilt-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB
Altavoz incorporado1 built-in speaker
Evento
Evento BásicoMotion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,exception
LinkageNotify surveillance center,send email,trigger recording,trigger capture,audible warning
Certificaciones
ProtecciónIP54
General
alimentación12 VDC ± 25%, reverse polarity protection, 0.75 A, max. 9 W, Ø5.5 mm coaxial power plug
DimensiónØ124 mm × 119 mm (Ø4.89″ × 4.68″)
WeightApprox. 290 g (0.6 lb.)
With Package Weight: Approx. 390 g (0.8 lb.)
MaterialPlastic
Operating Condition-10 °C to 40 °C (-14 °F to 104 °F). Humidity 90% or less (non-condensing)
Función generalHeartbeat,anti-banding,mirror,password protection,password reset via email
IdiomaEnglish, Ukrainian
